UF5 - 49 keybs Expandable USB MIDI Keyboard Controller

The keyboards include a USB port and one MIDI OUT, but with the optional FireWire card, you of course get a FireWire port, but you also get balanced analog I/O, digital I/O, MIDI IN/OUT/THRU, dual headphone outputs, and a microphone input. The Firewire expansion board also turns the keyboard into an audio interface. The keyboards all provide semi-weighted action, except for the UF8 which uses fully weighted keys.

The UF keyboard provides 8 knobs, 9 sliders, pitch-bend and modulation wheels for real-time control. There are also control buttons such as REC, PLAY, and REW, to remotely control the sequencer software. Other standard features for the UF series include after-touch and a breath control interface.

Specifications:
- 49 keys semi-weighted action keyboard with after-touch
- Pitch bend and modulation wheels
- 8 assignable control knobs, preset functions including Cutoff/ Resonance/ Attack/ Release/ PAN/ Reverb/ Chorus/ Tempo
- 9 assignable control faders, preset functions including volume for 1-16 channels and master volume, and drawbar for organ sounds.
- LED data display, control button including program, transpose, octave, channel, keyboard split and 6 sequencer remote buttons, including REC, PLAY, STOP, FAST FORWARD, REWIND AND RETURN TO START, etc.
- Breath control jack, 1 MIDI out port, Sustain pedal and volume pedal jack
- USB MIDI port, Power can be supplied via USB
- Win2000/XP and Mac OS X compatible
- Supports optional FireWire expansion board

FireWire Audio Expansion Board Specifications:
- 2 24bit/192kHz balanced line inputs
- 2 24bit/192kHz balanced line outputs
- 1 Mic in with professional preamp
- 1 IEEE1394 FireWire interface
- 1 S/PDIF digital I/O
- 2 headphone output
- 1 MIDI IN, OUT, THRU port
- 1 headphone volume control
